FUNCTION

SELECT:

UTILITY: INTERFACE: ASYNC TX TYPE

(CONDITIONAL)

ASYNC TX TYPE

RS232

IMPORTANT

Conditional: This menu is available only with Modem Type = ASYNC is
enabled and the Overhead card is installed.

Select EIA-232, EIA-485(4-WIRE), or EIA-485(2-WIRE) for ASYNC overhead type.

FUNCTION

SELECT:

UTILITY: INTERFACE: ASYNC RX TYPE

(CONDITIONAL)

ASYNC RX TYPE

RS232

IMPORTANT

Conditional: This menu is available only with Modem Type = ASYNC is
enabled and the Overhead card is installed.

Select EIA-232, EIA-485(4-WIRE), or EIA-485(2-WIRE) for ASYNC overhead type.

FUNCTION

SELECT:

UTILITY:

INTERFACE: IDR TX ESC TYPE

(CONDITIONAL)

IDR TX ESC TYPE

2-32K

AUDIO

IMPORTANT

Conditional: This menu is available only with Modem Type = IDR is
enabled and the Overhead card is installed.

Select 2-32K Audio or 64K Data for the IDR TX ESC type.
