SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–41
FUNCTION SELECT: CONFIGURATION: INTERFACE:
INSERT CHANNEL ADJUSTMENTS (CONDITIONAL)
INSERT CHANNEL
ASSIGNMENTS
IMPORTANT
Conditional: This menu is only available when the optional D&I are
installed has been selected for Modem Type in the Utility menu and the
Overhead Card is installed.
Programs the satellite channels into the following desired terrestrial frame slot:
• INSERT SAT CHANNEL TERR (For T1, T1_ESF, T1_S, T1_ESF_S)
• INSERT SAT T-SLOT TERR (For all other formats)
Note: The number of satellite channels inserted is data rate independent. The number of
channels is DR/64 kbps. When the data rate is 64 kbps only one channel is inserted.
When the data rate is 1920 kbps, 30 channels are inserted.
Upon entry, satellite channel 1 and the current terrestrial frame slot are displayed. Press
[
↑ ] or [ ↓ ] to select the satellite channel to be programmed. Press [ENTER] to choose the
satellite channel to be programmed. Press [ ↑ ] or [ ↓ ] to select the terrestrial frame slot for
each available satellite channel by incrementing or decrementing the digit at the flashing
cursor. If a time slot is unused, select NI (Not Inserted). Press [ENTER] to execute the
change.
INSERT SAT ---> 1
CHANNEL TERR -> 1
INSERT SAT ---> 1
T-SLOT TERR -> 1
