SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–78
FUNCTION SELECT: STORED FLTS/ALMS: OUTDOOR UNIT
OUTDOOR UNIT X
_ _ _ _ _
Displays the stored outdoor unit fault or alarm, such as:
• CURRENT ODU POWER ON ONLY
• VOLTAGE ODU POWER ON ONLY
• TEMPERATURE FSK ONLY
• PLL LOCK FSK ONLY
• CHECKSUM FSK ONLY
FUNCTION SELECT: STORED FLTS/ALMS:
UNAVAILABLE SECONDS (CONDITIONAL)
UNAVAL SECONDS X
STORED TIME/DATE
IMPORTANT
Conditional: This is available only with the Reed-Solomon option.
A fault is indicated if the Reed-Solomon Codec could not correct bit errors in one block
of serialized data in any given second.
FUNCTION SELECT: STORED FLTS/ALARMS: CLEAR
CLEAR ??
STORED FAULTS
To clear the currently logged stored faults, press [ENTER] when the “Clear Stored
Faults/Yes?” selection is displayed.
