Page 366: A.3.4 system configuration commands
SDM-300L3 Satellite Modem
Revision 1
Remote Control Operation
MN/SDM300L3.IOM
A–14
IBS Receive
ESC Type
Command:
Response:
Status:
Response:
Where: xxxxx = DATA (64K DATA) or AUDIO
(2x32K AUDIO).
Note: RX IBS Overhead only.
A.3.4
ODU Configuration Status
Outdoor Unit
Address
Command:
Response:
Status:
Response:
Where XX = 1 to 15.
Outdoor Unit
TX Output
Command:
Response:
Status:
Response:
Where xxx = ON or OFF.
Outdoor Unit
Power
Leveling
Command:
Response:
Status:
Response:
Where xxx = ON or OFF
A.3.4
System Configuration Commands
Time Of
Day
Command:
Response:
Status:
Response:
Where:
hh = 1 to 12 (hours).
mm = 00 to 59 (minutes).
xx = AM or PM.
Date
Command:
Response:
Status:
Response:
Where:
mm = 1 to 12 (month).
dd = 1 to 31 (day).
yyyy = 00 to 99 (year) in 2 - digit year mode, and 1975
to 1999 and 2000 to 2075 in 4 - digit mode.
Remote Command:
Response:
Configures the modem for remote operation.
The SDM300L will respond to any status request at any
time. However, the SDM300L must be in 'Remote Mode'
to change configuration parameters.
Clear
Stored
Faults
Command:
Response:
This command is used to clear all stored faults logged by
the SDM300L.
Modem
Operation
Mode
Command:
Response:
Status:
Response:
Where: xxxxxxx = TX_ONLY, RX_ONLY, or DUPLEX.
This command configures the modem for simplex or
duplex operation modes. When transmit only mode is
selected, receive faults are inhibited and when receive
only mode is selected, transmit faults are inhibited.
System
Modem
Type
Command:
Response:
Status:
Response:
Where: xxxxxx = IDR, IBS, DI, ASYNC, AUPC, EFD,
VSAT, 309 or CUSTOM.
Save
Modem
Config.
Command:
Response:
Where: n = 1, 2, 3, 4, or 5 (stored configuration number).
This command saves the current modem configuration for
recall at a later time using the 'RMC_' command. Up to
five different modem configurations can be saved.
