SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–34
Upon entry, the current TX data fault that is being monitored is displayed. Press [ ↑ ] or [ ↓ ]
to make the selection. Press [ENTER] to execute the change.
FUNCTION SELECT: CONFIGURATION: INTERFACE:
RX DATA FAULT (CONDITIONAL)
RX DATA FAULT
NONE
IMPORTANT
Conditional: This menu is only available when the overhead interface
PCB is installed.
Receive data fault. Selects a receive interface fault monitor of NONE, AIS, or DATA.
The data monitored for RX data is coming from the satellite. Refer to TX DATA FAULT
for a description of function choices.
Upon entry, the current, monitored RX DATA FAULT is displayed. Press [
↑ ] or [ ↓ ] to
make the selection. Press to execute the change.
FUNCTION SELECT: CONFIGURATION: INTERFACE:
TX 2047 PATTERN (CONDITIONAL)
TX 2047 PATTERN
OFF
IMPORTANT
The is a Test Mode. Conditional: This menu is only available when the
overhead interface PCB is installed.
Programs the transmitter to On or Off to insert a 2047 pattern instead of the normal
transmit data.
Upon entry, the current status is displayed. Press [
↑ ] or [ ↓ ] to make the selection. Press
to execute the change.
