SDM-300L3 Satellite Modem Revision 1
Remote Control Operation MN/SDM300L3.IOM
A–12
Bulk Drop
Channels
Assignment Command:
Response:
Status:
Response: >add/BDCA_dd;cc_dd;cc_dd;cc_dd;cc......'cr''lf']
>add/BDCA_dd;cc_dd;cc_dd;cc_dd;cc......'cr''lf'] Where:
dd = 1 to N (over the satellite drop channel);
where N = (modulator data rate) divided by
(64 kbps).
cc = 1 to 24 (terrestrial channel number for
T1 data formats).
cc = 1 to 31 (terrestrial time slot number for
E1 data formats).
Notes:
1. The status response returns
programming information for 1 to N drop
channels.
2. This command is not valid when the
drop data format is specified as E1CAS
and the modulator data rate is set to
1920.0 kbps.
Insert
Channels
Assignment Command:
Response:
Status:
Response: >add/ICA_ii;cc'cr''lf']
>add/ICA_ii;cc'cr''lf']
Where:
ii = 1 to N (over the satellite insert channel);
where N = (demodulator data rate) divided by
(64 kbps).
cc = 1 to 24 (terrestrial channel number for
T1 data formats).
cc = 1 to 31 (terrestrial time slot number for
E1 data formats).
cc = 0 if no insert is desired for the specified
insert channel.
Notes:
1. Time slot 16 (cc = 16) may not be
specified when the insert data format is
specified to be E1CAS.
2. This command is not valid when the
insert data format is specified as E1CAS
and the demodulator data rate is set to
1920.0 kbps.
Bulk Insert
Channels
Assignment Command:
Response:
Status:
Response: >add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr''lf']
>add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr''lf']
Where:
ii = 1 to N (over the satellite insert channel);
where N = (modulator data rate) divided by
(64 kbps).
cc = 1 to 24 (terrestrial channel number for
T1 data formats).
cc = 1 to 31 (terrestrial time slot number for
E1 data formats).
cc = 0 if no insert is desired for the specified
insert channel.
Notes:
1. The status response returns
programming information for 1 to N insert
channels.
2. Time slot 16 (cc = 16) may not be
specified when the insert data format is
specified to be E1CAS.
3. This command is not valid when the
insert data format is specified as E1CAS
and the demodulator data rate is set to
1920.0 kbps.
ASYNC
Transmit
Overhead
Baud Rate Command:
Response:
Status:
Response: >add/TOBR_nnnnn'cr''lf']
>add/TOBR_nnnnn'cr''lf']
Where: nnnnn = 110, 150, 300, 600, 1200, 2400,
4800, 9600, 19200, or 38400.
Note: TX ASYNC Overhead only.
