SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–43
FUNCTION SELECT: CONFIGURATION: INTERFACE:
ASYNC TX LENGTH (CONDITIONAL)
ASYNC TX LENGTH
7 BITS
IMPORTANT
Conditional: The menu is only available when Modem Type = ASYNC
and requires that the Overhead Card is installed.
Programs the ASYNC overhead transmit word length for 5, 6, 7, or 8 bits.
Upon entry, the current status of the ASYNC TX word length is displayed. Press [
↑ ] or
[ ↓ ] to make the selection. Press to execute the change.
FUNCTION SELECT: CONFIGURATION: INTERFACE:
ASYNX RX LENGTH (CONDITIONAL)
ASYNC RX LENGTH
7 BITS
IMPORTANT
Conditional: The menu is only available when Modem Type = ASYNC
and requires that the Overhead Card is installed.
Programs the ASYNC overhead receive word length for 5, 6, 7, or 8 bits.
Upon entry, the current status of the ASYNC RX word length is displayed. Press [
↑ ] or
[ ↓ ] to make the selection. Press to execute the change.
