SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–89
FUNCTION SELECT: UTILITY: MODULATOR:
TX BPSK ORDERING
TX BPSK ORDERING
STANDARD
TX BPSK bit ordering selection. Select STANDARD or NON-STANDARD.
FUNCTION SELECT: UTILITY: MODULATOR:
MOD SPECTRUM
MOD SPECTRUM
NORMAL
Programmable vector rotation allows the operator to select NORMAL or INVERT for
spectrum reversal of the I and Q baseband channels.
FUNCTION SELECT: UTILITY: MODULATOR: TX-RS N/K DEEP
(CONDITIONAL)
TX-RS N/K DEEP
225/205
8
IMPORTANT
Conditional: This menu is active when Reed-Solomon (RS) is installed
and RS is On (under Configuration: Modulator).
N/K is status only.
Deep is interleaver depth and is programmable to a depth of 4, 8, or 16.
