SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–65
FUNCTION SELECT: MONITOR: ODU VOLTAGE
ODU VOLTAGE
XX.X VOLTS
Monitors the ODU voltage or “ODU POWER OFF.”
Voltage displayed is 0 to 64 volts, in 0.1 volt increments.
FUNCTION SELECT: MONITOR: ODU OUTPUT LEVEL
(CONDITIONAL)
ODU OUTPUT LEVEL
xx.xx dBm
IMPORTANT
Conditional: This menu is displayed when the FSK and ODU POWER
SUPPLY are On under the Configuration: Modulator menu.
Displays ODU output power as reported by an FSK capable BUC.
FUNCTION SELECT: MONITOR: ODU OUTPUT LEVEL
(OPTIONAL) (CONDITIONAL)
ODU OUTPUT LEVEL
xx.xx/xx.xxT dBm
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are On, under the Configuration: Modulator menu, and Power
Leveling is On under the Utility: Outdoor Unit menu.
Displays ODU output power, as reported by an FSK capable BUC, and the ODU output
power target (T), that was set when Power Leveling was turned On.
