SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–105
FUNCTION SELECT:UTILITY:INTEFACE:
IDR BACKWARD ALARM CONTROL (CONDITIONAL)
IDR BACKWARD
ALARM CONTROL
IMPORTANT
Conditional: This selection is available only when Modem Type = IDR is
enabled and the Overhead card is installed.
Controls IDR monitor and alarm functions when not using a communications link. Use
this option to select ON or OFF for the RX and TX alarms.
Press [
↑ ] or [ ↓ ] to select the backward alarm RX or TX numbers 1 through 4. Press
[ENTER] to execute the change.
BW ALARM RX #4
ON
BW ALARM RX #3
ON
BW ALARM RX #2
ON
BW ALARM RX #1
ON
BW ALARM TX #4
ON
BW ALARM TX #3
ON
BW ALARM TX #2
ON
BW ALARM TX #1
ON
