FUNCTION SELECT: CONFIGURATION: INTERFACE:
RX 2047 PATTERN (CONDITIONAL)
RX 2047 PATTERN
OFF
IMPORTANT
The is a Test Mode. Conditional: This menu is only available when the
overhead interface PCB is installed.
Programs the modem to receive a 2047 pattern as the normal receive data, and allows the
BER monitor to work on that 2047 pattern.
Upon entry, the current status is displayed. Press [
↑ ] or [ ↓ ] to select on or off. Press
to execute the change.
FUNCTION SELECT: CONFIGURATION: INTERFACE:
TX CODING FORMAT (CONDITIONAL)
TX CODING FORMAT
OFF
IMPORTANT
Conditional: This menu is only available when the TX G.703 interface is
programmed. This requires that the optional Overhead card is installed.
Programs the transmitter for AMI, B8ZS, or HDB3 coding of the baseband data.
Upon entry, the current coding format is displayed. Press [
↑ ] or [ ↓ ] to make the selection.
Press to execute the change.
