SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–109
4.6.6.5 FUNCTION SELECT: UTILITY: OUTDOOR UNIT (CONDITIONAL)
UTILITY
OUTDOOR UNIT
IMPORTANT
Conditional: This menu is available only when ODU Power Supply, FSK,
and TX-IF Output are On.
FUNCTION SELECT: UTILITY: OUTDOOR UNIT:
ODU FSK ADDRESS (CONDITIONAL)
ODU FSK ADDRESS
1
IMPORTANT
Conditional: This menu is available only when ODU Power Supply, FSK,
and TX-IF Output are On.
Selects the address the modem will use to communicate with an FSK capable ODU.
Address shall be within 1 to 15. This does not change the address in the ODU. It allows the
user to match the address in the modem’s FSK communication link to the one in the ODU.
Press [
↑ ] or [ ↓ ] to select the ODU FSK Address. Press [ENTER] to execute the change.
