SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–48
FUNCTION SELECT: CONFIGURATION: LOCAL AUPC:
MAXIMUM POWER (CONDITIONAL)
MAXIMUM POWER
-5.0 dBm
IMPORTANT
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
Programs the maximum power level of the AUPC. The maximum power level can range
from 0 to -40 dBm, in 0.5 dBm steps.
FUNCTION SELECT: CONFIGURATION: LOCAL AUPC:
TARGET EB/NO (CONDITIONAL)
TARGET EB/NO
6.0 dB
IMPORTANT
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
Manufacturer does not recommend a setting greater than 15.5 dB.
Programs the E
b
/N
0
target set point. The E
b
/N
0
target set point ranges from 3.2 to
16.0 dB, in 0.1 dB steps
