SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–67
FUNCTION SELECT: MONITOR: ODU SOFTWARE
(CONDITIONAL)
ODU SOFTWARE
VER: XX
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays the ODU current software version 0 to 15 of an FSK capable BUC.
FUNCTION SELECT: MONITOR: ODU POWER CLASS
(CONDITIONAL)
ODU POWER CLASS
XX WATTS
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays the Power Class from 0 to 60 watts of an FSK capable BUC.
FUNCTION SELECT: MONITOR: TX L-BAND FREQ
(CONDITIONAL)
TX L-Band FREQ
1200.0000 MHz
IMPORTANT
Conditional: This menu is displayed when the TX Terminal LO
(frequency) and Mix are programmed under the Utility: Modulator TX
Terminal LO menu.
Displays the TX L-Band frequency within 950 to 1750 MHz.
