SDM-300L3 Satellite Modem
Revision 1
Remote Control Operation
MN/SDM300L3.IOM
A–31
Interface
Receive Side
Stored Faults
Command:
Response:
UNFL_xxx'cr'
OVFL_xxx'cr'
RXD_xxx'cr'
FBER_xxx'cr'
BWA_xxx'cr'
CLK_xxx'cr'
PLL_xxx'cr'
DMUX_xxx'cr'
2047_xxx'cr'
BUFF_xxx'cr'
INS_xxx'cr'
RAC1_xxx'cr'
RAC2_xxx'cr'
CONF_xxx'cr''lf']
Buffer Underflow (OK/FLT)
Buffer Overflow (OK/FLT)
Receive Data Loss/AIS (OK/FLT)
Frame BER (OK/FLT)
Receive Backward Alarm (OK/FLT)
Selected Buffer Clock Activity (OK/FLT)
Buffer Clock PLL Lock (OK/FLT)
Demux Lock (OK/FLT)
2047 Pattern Lock Detect (OK/FLT)
Buffer Full (OK/FLT)
D&I Insert (OK/FLT)
Receive Audio Clip Channel #1 (OK/FLT)
Receive Audio Clip Channel #2 (OK/FLT)
Configuration (OK/FLT)
Common
Equipment
Stored Faults
Command:
Response:
M&C_xxx'cr'
INT_xxx'cr'
BAT_xxx'cr'
+5_xxx'cr'
+12_xxx'cr'
-12_xxx'cr'
ST_xxx'cr''lf']
Monitor & Control Module (OK/FLT)
Data Interface/Overhead Module (OK/FLT)
Battery/Clock (OK/FLT)
+5V Power Supply (OK/FLT)
+12V Power Supply (OK/FLT)
-12V Power Supply (OK/FLT)
Self Test (OK/FLT)
Interface
Alarms
Stored Faults
Command:
Response:
TXBWA1_xxx'cr'
TXBWA2_xxx'cr'
TXBWA3_xxx'cr'
TXBWA4_xxx'cr'
RXBWA1_xxx'cr'
RXBWA2_xxx'cr'
RXBWA3_xxx'cr'
RXBWA4_xxx'cr''lf']
TX Backward Alarm 1 (FLT/OK)
TX Backward Alarm 2 (FLT/OK)
TX Backward Alarm 3 (FLT/OK)
TX Backward Alarm 4 (FLT/OK)
RX Backward Alarm 1 (FLT/OK)
RX Backward Alarm 2 (FLT/OK)
RX Backward Alarm 3 (FLT/OK)
RX Backward Alarm 4 (FLT/OK)
Reed-
Solomon
Unavailable
Seconds
Command:
Response:
UNA_xxx'cr''lf']
Unavailable Seconds (FLT/OK)
Outdoor Unit
Status
TX L-Band
modem
Command:
Response:
CURRENT_xxx'cr'
VOLTAGE_xxx'cr'’lf’]
Current (FLT/OK)
Voltage (FLT/OK)
