Front Panel Operation MN/SDM300L3.IOM
4–103
FUNCTION SELECT: UTILITY: INTERFACE:
FRAMING STRUCTURE: INTERFACE: FRAMING STRUCTURE:
T1 FRAMING
T1 FRAMING
STRUCTURE: G.704
Upon entry, the framing type (T1 or E1) is displayed on Line 1. The framing structure of
each type (None or G.704) is displayed on Line 2.
Press [
← ] or [ → ] and [ ↑ ] or [ ↓ ] to select framing structure and type.
Press to execute the change.
FUNCTION SELECT: UTILITY: INTERFACE:
FRAMING STRUCTURE: E1 FRAMING
E1 FRAMING
STRUCTURE: G.704
Upon entry, the framing type (T1 or E1) is displayed on Line 1. The framing structure of
each type (None or G.704) is displayed on Line 2.
Press [
← ] or [ → ] and [ ↑ ] or [ ↓ ] to select framing structure and type.
Press to execute the change.
FUNCTION SELECT:UTILITY: INTERFACE: RTS TX-IF CNTRL
RTS TX-IF CNTRL
OFF
Programs the modem to allow a Request To Send (RTS) signal to enable or disable the
output carrier when data is ready for transmission.
