SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–52
FUNCTION SELECT: CONFIGURATION: MUX:TRIBUTARY #N
TRIBUTARY #N
2048.0Kbps RS422
N = 1 through 7
TRIBUTARY #8
DISABLED RS232
Range: 0.6 to 4000.0 kbps (in 100 bps steps) or DISABLED, RS232, or RS422
Select the tributary number (1 through 8), data rate (0.6 to 4000 kbps), and
interface type
(RS-232 or RS-422). Repeat these selections for up to 8 tributaries.
FUNCTION SELECT: CONFIGURATION: MUX:TRIBUTARY #N
TRIBUTARY #N
CLK:NRM DATA:NRM
N = 1 through 8
NRM or INV (for both clock and data phase)
Select the clock type and data phase type for each tributary.
FUNCTION SELECT: CONFIGURATION: MUX:TRIBUTARY#N
TRIBUTARY #N
MD: SYNC AF:7E2
N = 1 through 8
MODE: SYNC or ASYNC ASYNC FORMAT: 7E1, 7O1, 7N2, 7E2, 7O2, 8N1
or 8N2
Select the mode. If ASYNC is chosen, select the ASYNC FORMAT as well.
