Table 14-7. Demodulator Digital Data Rate (Continued)
Modulation Type
Encoding Type Data Rate Range
BPSK 1/2
QPSK 1/2, 3/4
QPSK 1/2, 3/4
QPSK 1/2, 3/4
QPSK 3/4
QPSK 7/8 ASYNC
IBS
D&I
ASYNC
ASYNC
ASYNC 2.4 kbps
64 kbps
64 kbps
4.8 kbps
7.2 kbps
8.4 kbps 1024 kbps
2048 kbps
1920 kbps
2048 kbps
2048 kbps
2048 kbps
BPSK 1/2
QPSK 1/2, 3/4
QPSK 1/2, 3/4
QPSK 1/2, 3/4
QPSK 3/4
QPSK 7/8 ASYNC and Reed-Solomon
IBS and Reed-Solomon
D&I and Reed-Solomon
ASYNC and Reed-Solomon
ASYNC and Reed-Solomon
ASYNC and Reed-Solomon 2.4 kbps
64 kbps
64 kbps
4.8 kbps
7.2 kbps
8.4 kbps 1024 kbps
2048 kbps
1920 kbps
2048 kbps
2048 kbps
2048 kbps
QPSK 3/4
QPSK 3/4 IDR, T1
IDR, E1 1544 kbps
2048 kbps Fixed Rate
QPSK 3/4
QPSK 3/4 IDR, T1, and Reed-Solomon
IDR, E1, and Reed-Solomon 1544 kbps
2048 kbps Fixed Rate
8-PSK 2/3
QPSK 1/2
8-PSK 2/3 IBS
D&I
ASYNC 512 kbps
64 kbps
512 kbps 2048 kbps
1920 kbps
2048 kbps
8-PSK 2/3
QPSK 1/2
8-PSK 2/3 IBS and Reed-Solomon
D&I and Reed-Solomon
ASYNC and Reed-Solomon 512 kbps
64 kbps
512 kbps 2048 kbps
1920 kbps
2048 kbps
8-PSK 2/3
8-PSK 2/3 IDR, T1
IDR, E1 1544 kbps
2048 kbps Fix Rate
8-PSK 2/3
8-PSK 2/3 IDR, T1, and Reed-Solomon
IDR, E1, and Reed-Solomon 1544 kbps
2048 kbps Fix Rate
BPSK 1/1
{O}QPSK 1/1 None
None 4.8 kbps
9.6 kbps 2.5 Mbps
5.0 Mbps
