SDM-300L3 Satellite Modem

Revision 1

Front Panel Operation

MN/SDM300L3.IOM

4–90

FUNCTION

SELECT:

UTILITY:MODULATOR: TX IESS-310 MODE

(CONDITIONAL)

TX IESS-310 MODE

OFF

IMPORTANT

Conditional: Only available when 8-PSK option and RS option are
installed and selected.


An On indication enables 8-PSK 2/3 with Reed-Solomon.

FUNCTION

SELECT:

UTILITY:MODULATOR: TX IESS-315 MODE

(CONDITIONAL)

TX IESS-315 MODE

OFF

IMPORTANT

Conditional: Only available when the Turbo option is installed and
selected.


An On indication enables Intelsat type scrambling with Turbo.

FUNCTION SELECT: UTILITY: MODULATOR: TX MODE

TX MODE

CONTINUOUS


Selection of TX Mode IN Continuous or Burst.
