SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–66
FUNCTION SELECT: MONITOR: ODU TEMPERATURE
(CONDITIONAL)
ODU TEMPERATURE
+ XX
°
C/OK
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays ODU (BUC) temperature of 00
± 99 ° C of an FSK capable BUC.
FUNCTION SELECT: MONITOR: ODU PLL LOCK
(CONDITIONAL)
ODU PLL LOCK
OK/UNLOCKED
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays the ODU PLL Lock status of an FSK capable BUC. The ODU PLL requires that
the ODU 10 MHz reference is On under the Configuration: Modulator menu.
