SDM-300L3 Satellite Modem

Revision 1

Front Panel Operation

MN/SDM300L3.IOM

4–83

4.6.6

FUNCTION SELECT: UTILITY

FUNCTION SELECT

UTILITY



The Function Select: Utility menu is divided into the following categories:

4.6.6.1

FUNCTION SELECT: UTLITY: FIXED MODEM RATE

UTILITY

FIXED MODEM RATE

FUNCTION SELECT: UTLITY: FIXED MODEM RATE:

CODE

RATE/DATA

RATE

(CONDITIONAL)

CR: _____________

DR: ___________Kb


IMPORTANT

This menu is displayed when the modem has the Single Data Rate
option and the code/data rates are not programmed.

•

If CR/DR is blank, user is allowed to enter code and data rate one time.

•

If CR/DR is displayed, then fixed code/data rate is shown
