SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–63
FUNCTION SELECT: MONITOR: BUFFER FILL
BUFFER FILL
50%
Displays the current plesiochronous buffer fill status percent. Range: 1 to 99%.
FUNCTION SELECT: MONITOR: FRAME ERRORS
(CONDITIONAL)
FRAME ERRORS
n.n E-e
2047 ERRORS
n.n E-e
IMPORTANT
Conditional: This menu available only when the optional Overhead
Card is installed.
Displays the current framing pattern bit error rate or “No Data” (if carrier is not locked).
Monitors the currently selected READ_ERROR function.
Range: < mm.m E-e to > mm.m E-e.
Notes:
1. Low limit is based on performance.
2. High limit is based on the data/code rate.
Frame Errors Measured when framed modes of operation are active.
2047 Errors Measured when the RX 2047 PATTERN (under the Configuration: Interface
menu) is tuned On.
