SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–77
FUNCTION SELECT: STORED FLTS/ALMS: COMMON
COMMON X
STORED TIME/DATE
Displays the stored date and time of a fault or alarm, such as:
• BATTERY/CLOCK
• -12 VOLT SUPPLY
• +12 VOLT SUPPLY
• +5 VOLT SUPPLY
• SELF TEST
• CONTROLLER
• INTERFACE MODULE
FUNCTION SELECT: STORED FLTS/ALMS: BACKWARD ALRMS
(CONDITIONAL)
BACKWARD ALRMS X
STORED TIME/DATE
IMPORTANT
Conditional: Only available with IDR selected for Modem Type.
Displays the stored date and time of a fault or alarm, such as:
• BW ALRM RX #4
• BW ALRM RX #3
• BW ALRM RX #2
• BW ALRM RX # 1
• BW ALRM TX #4
• BW ALRM TX #3
• BW ALRM TX #2
• BW ALRM TX # 1
