SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–124
Notes:
1. When the Overhead card with the ASYNC/AUPC option is installed, and the
self-monitoring Local Modem AUPC mode is needed, do not select ASYNC as
the Modem Type.
2. When the Reed-Solomon card with AUPC option is installed, select AUPC from
the Modem Type menu (under Utility: Modem Type menu) when AUPC between
two modems is needed.
3. The Modem must be configured for Duplex operation and the demodulator
locked to the modulator signal.
FUNCTION SELECT: UTILITY: MODEM TYPE: MODEM SERIAL #
MODEM SERIAL #
012345678
Status Only.
Displays the modem serial number.
FUNCTION SELECT: UTILITY: MODEM TYPE:
CARD #1 SERIAL #
CARD #1 SERIAL #
012345678
Status Only.
Displays the CARD #1 serial number.
