SDM-300L3 Satellite Modem
Revision 1
Remote Control Operation
MN/SDM300L3.IOM
A–25
MINP_snn.n'cr' (Note
5)
MAXP_snn.n'cr' (Note
5)
LCL_xxxx'cr'
(Note 5)
RCL_xxxx'cr' (Note
5)
ENSP_nn.n'cr' (Note
6)
MAXT_n.n'cr' (Note
6)
RTSM_xxx'cr'
TSD_xx'cr'
IDRT_xxxxx'cr' (Note
3)
IDRR_xxxxx'cr' (Note
4)
IBST_xxxxx'cr' (Note
3)
IBSR_xxxxx'cr' (Note
4)
AUPC Minimum Power Value
AUPC Maximum Power Value
AUPC Local Carrier Loss
AUPC Remote Carrier Loss
AUPC EBN0 Target Set Point
AUPC Max. Tracking Rate
RTS TX-IF Control Mode
CTS Delay Time
IDR Transmit ESC Type
IDR Receive ESC Type
IBS Transmit ESC Type
IBS Receive ESC Type
The Interface configuration status command causes a block of
data to be returned by the addressed MODEM. The block
reflects the current configuration of the interface. Additional
configuration status of new options and features will always be
appended to the end.
Notes:
1. Data is only returned for TX D&I Overhead.
2. Data is only returned for RX D&I Overhead.
3. Data is only returned for TX IDR Overhead.
4. Data is only returned for RX IDR Overhead.
5. Data is only returned for TX ASYNC Overhead.
6. Data is only returned for RX ASYNC Overhead.
7 Not
Used.
thru
14.
Current
Receive
Reed
Solomon N/
K and
Interleaver
value
Command:
Response:
Where: nn = N value, kkk = K value and ii = Interleaver value.
Descrambler
Type
Command:
Response:
Where xxxxxxxxxxxx = IBS SYNC, EFD MOD V.35, INTELSAT
V.35, FDC MOD V.35, ITU V.35 or OFF.
