SDM-300L3 Satellite Modem
Revision 0
Specifications
MN/SDM300L3.IOM
14–32
14.12.2
V.35 Specification V.10, V.11 Specification, Circuit Supported
Circuit Supported
SD, SCT, SCTE, RD, SCR, DSR, RLSD, RTS, CTS, MC,
DSR, LL
Driver Amplitude (RD, SCR, SCTE, CTS,
RLSD, DSR, SCTE)
±
0.5V-PK,
±
20% differential, into 100
Ω
Amplitude (SCT, SD, RTS, LL, MC)
±
0.2V Minimum into 100
Ω
Polarity (SD, SCT, SCTE, RD, SCR)
1 (True) when B positive with respect to A
0 (False) when A positive with respect to B
Polarity (RTS, CTS, DSR, RLSD)
1 (True) when < -0.2V with respect to ground
0 (False) when > +0.2V with respect to ground
Phasing (SCTE, SCR)
0 to 1 (False-to-True) transition nominally in center of
data bit
Symmetry (SCT, SCTE, SCR)
50%,
±
5%
SD-A, SD-B
Send Data
SCT-A, SCT-B
Serial Clock Transmit
RD-A, RD-B
Receive Data
SCR-A, SCR-B
Serial Clock Receive
SCTE-A, SCTE-B
Transmitter Signal Timing
MC-A, MC-B
Master Clock
RTS
Request to Send
CTS
Clear to Send
DSR
Data Set Ready
RLSD
Receive Line Signal Detect
LL Local
Loopback
MF
Mod Fault (ttl)
DF
Demod Fault (ttl)
Note: All other specifications are per CCITT V.10 and V.11.
