SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–51
4.6.1.2 FUNCTION SELECT: CONFIGURATION: MUX
(OPTIONAL/CONDITIONAL)
IMPORTANT
Conditional: This menu is available only if the optional MUX card
(slot #1) is installed.
CONFIGURATION
MUX
The multiplexer (MUX) system provides for 1 to 8 tributary channels to be multiplexed
onto a single aggregate carrier. Independent tributary data rates from 600 bps to 4000
kbps in 100 bps increments are supported. This option is used primarily with the SDR-54
receiver. Up to 8 tributaries can be configured. For each tributary, choose the following:
• Data Rate
• Interface Type
• Mode
• ASYNC Format
• Clock
• Data Phase
