Configuration SDM-650B Satellite Modem
3–18 Rev. 5
3.2.2.2 Connector Pinouts
The V.35 interface is provided on the industry standard 34-pin block connector accessible
from the rear panel of the modem. Screw locks are provided for mechanical security of
the mating connector.
Signal Function Name Pin #
SIGNAL GROUND SG A, B
SEND DATA SD-A
SD-B P
S
SERIAL CLOCK TRANSMIT SCT-A
SCT-B Y
(AA)
RECEIVE DATA RD-A
RD-B R
T
REQUEST TO SEND RTS C
SERIAL CLOCK RECEIVE SCR-A
SCR-B V
X
CLEAR TO SEND CTS D
DATA SET READY DSR E
RECEIVE LINE SIGNAL DETECT RLSD F
SERIAL CLOCK TRANSMIT EXT SCTE-A
SCTE-B U
W
MODULATOR FAULT − (MM) m
DEMODULATOR FAULT − (NN) n
MASTER CLOCK
(INPUT) MC-A
MC-B (CC) c
(DD) d
