Asynchronous Overhead Channel Unit SDM-650B Satellite Modem
F–20 Rev. 5
F.5.2 Menu Explanations
F.5.2.1 Select Configuration
Refer to Table F-3.
Modem configuration may be viewed or changed by entering the Config menu from the
Select menu on the front panel. After entering the Config menu, use
[ ← ] and [ → ] to select
one of the following configurations:
• MOD
• DEMOD
• INTERFACE
• AUPC
Enter the selected Config menu by pressing [ENTER]. Use
[ ← ] and [ → ] to view the
selected configuration parameters. Press [ENTER] to begin the configuration process.
Then, use the arrow keys to make the changes.
After the changes are made and the display represents the correct parameters, execute the
change by pressing [ENTER]. When [ENTER] is pressed, the necessary programming is
initiated by the modem. Press [CLEAR] to interrupt the process.
The following sections describe each configuration function in detail.
