Remote Control Operation SDM-650B Satellite Modem
B–6 Rev. 6
B.1.3.5 Set Modulator Power Offset
Command:
Response: >add/MPO_snn.n”cr””lf”]
Status Only: Response:
>add/MPO_snn.n”cr””lf”]
Where: snn.n = +20.0 to -20.0, in 0.5 dB increments.
Notes:
1. This will be the highest modulator power that will be displayed and programmed.
2. Use the MOP_ command to actually change the modulator output power.
B.1.3.6 Set Modulator Output Power Level
Command:
Response: >add/MOP_snn.n”cr””lf”]
Status Only: Response:
>add/MOP_snn.n”cr””lf”]
Where:
snn.n = +20.0 to -45.0, in 0.5 dB increments for 140 MHz modulators.
snn.n = +20.0 to -30.0, in 0.5 dB increments for 70 MHz modulators.
Notes:
1. Power levels may be programmed for a maximum value specified by the
modulator power offset with a range of 25 dB and 10 dB below the maximum
value for the 140 MHz modulator and the 70 MHz modulator, respectively.
2. See the MPO_ command specification for more information.
