SDM-650B Satellite Modem Remote Control Operation
Rev. 6 B–61
B.2.8.5 Common Equipment Status
The common equipment status command causes a block of data to be returned which
indicates the status of the common equipment.
Command:
Response: >add/CES_”cr”
M&C_xxx”cr”
Monitor and Control Module (OK/FLT)
INT_xxx”cr” Data Interface Module (OK/FLT)
BAT_xxx”cr” Battery (OK/FLT)
PS1_xxx”cr” +5V Power Supply (OK/FLT)
PS2_xxx”cr” +12V Power Supply (OK/FLT)
PS3_xxx”cr” -12V Power Supply (OK/FLT)
MODE_xxxxxx”cr” Mode (LOCAL or REMOTE)
SW_x.xxx”cr” Software Version
SFLT_xx”cr””lf”] Number of Stored Faults Logged (0 to 10)
B.2.8.6 Interface Transmit Side Status
Command:
Response: >add/ITXS_”cr”
CLK_xxx”cr”
Selected Transmit Clock Activity
(OK/FLT)
PLL_xxx”cr” Transmit Synthesizer PLL Lock
(OK/FLT)
SFLT_xx”cr””lf”] Number of Stored Faults Logged (0 to 10)
B.2.8.7 Interface Receive Side Status
Command:
Response: >add/IRXS_”cr”
MUX_xxx”cr”
MUX Lock (OK/FLT)
CLK_xxx”cr” Selected Buffer Clock Activity
(OK/FLT)
PLL_xxx”cr” Receive Synthesizer PLL Lock
(OK/FLT)
(See Note) OVFL_xxx”cr” Buffer Overflow (OK/FLT)
(See Note) UNFL_xxx”cr” Buffer Underflow (OK/FLT)
(See Note) IBFS_nn%”cr” Interface Buffer Fill Status
SFLT_xx”cr””lf”] Number of Stored Faults Logged (0 to 10)
Note: Available with buffer support hardware only.
