SDM-650B Satellite Modem Asynchronous Overhead Channel Unit
Rev. 5 F–13
F.5.1 Menus and Options Overview
Refer to Section F.5.2 for menu and option explanations.
Note: The “A” after the software version designates “Asynchronous.”
Table F-3. Main Front Panel Menu with Asynchronous Overhead (with AUPC)
Screen Submenus/Options Comments
SDM650 “TYPE”
SW_4.12A This is an information-only screen.
The “A” on line 2 means the
asynchronous option is installed.
SELECT CONFIG MOD
DEMOD
INTRFACE
AUPC Go to Table F-4.
Go to Table F-5.
Go to Table F-6.
Go to Table F-7.
SELECT MONITOR Go to Table F-8.
SELECT FAULTS Go to Table F-9.
SELECT StFAULTS Go to Table F-10.
SELECT REMOTE Go to Table F-11.
SELECT UTILITY Go to Table F-12.
Table F-4. Select Configuration Modulator Menu (with AUPC)
Menus Submenus/Options Comments
TX-x Code_Rate x = A, B, C, D, or V
TX_Freq 50.000 to 90.000 MHz or 100.000 to
180.000 MHz In 2.5 kHz steps.
RF_Out ON
OFF
TX_Power
or
AUPC_PWR
-5.0 dBm to -30 dBm In 0.5 dBm steps.
When AUPC is turned ON in the
AUPC configuration menu, this
window will display AUPC_PWR.
DifEncdr ON
OFF
Scramblr ON
OFF
CW_Mode Center
Dual
Offset
