Asynchronous Overhead Channel Unit SDM-650B Satellite Modem
F–34 Rev. 5
F.5.2.5 Select Remote
Refer to Table F-11.
The remote functions may be viewed or changed by entering the Remote level from the
Select menu on the front panel. After entering the Remote menu, use
[ ← ] and [ → ] to select
Config or Monitor configuration. Enter the selected Configuration menu by pressing
[ENTER]. Use
[ ← ] and [ → ] to view the selected configuration parameters.
The following sections contain information on individual functional categories and their
respective functions.
F.5.2.5.1 Remote Configuration
AUPC Remote AUPC enable.
On entry, the current status of the remote AUPC is displayed with the flashing
cursor on the first character. Use the arrow keys to select ON or OFF. Press
[ENTER] to execute the change.
BBLOOPBK Programs the remote baseband loopback or ON or OFF.
On entry, the current status of the remote baseband loopback is displayed with
the flashing cursor on the first character. Use the arrow keys to select ON or
OFF. Press [ENTER] to execute the change.
TX 2047 Programs the remote TX 2047 pattern ON or OFF.
On entry, the current status of the remote TX 2047 is displayed with the flashing
cursor on the first character. Use the arrow keys to select ON or OFF. Press
[ENTER] to execute the change.
F.5.2.5.2 Remote Monitor
RX 2047 Receive 2047 BER. This is a monitor point that will display the current RX 2047
BER. If no data is available, the display will read “No Data.”
