Asynchronous Overhead Channel Unit SDM-650B Satellite Modem
F–28 Rev. 5
F.5.2.1.4 Configuration AUPC
Refer to Table F-7.
AUPC Programs the AUPC ON or OFF.
On entry, the current status is displayed with the flashing cursor on the first
character. Use the arrow keys to select ON or OFF. Press [ENTER] to
execute the change.
NOM PWR Programs the nominal power value of the AUPC.
On entry, the current nominal power value is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The nominal power value can range from -30
to -5 dBm. Press [ENTER] to execute the change.
MIN PWR Programs the minimum power level of the AUPC.
On entry, the current minimum power level is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The minimum power level can range from -30
to -5 dBm. Press [ENTER] to execute the change.
MAX PWR Programs the maximum power level of the AUPC.
On entry, the current maximum power level is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The maximum power level can range from -
30 to -5 dBm. Press [ENTER] to execute the change.
Eb/N0 SP Programs the E
b
/N
0
target setpoint.
On entry, the current E
b
/N
0
target setpoint is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The E
b
/N
0
target setpoint can range from 3.2
to 9.7 dB, in 0.1 dB increments. Press [ENTER] to execute the change.
MAX TR Programs the maximum tracking rate of the AUPC.
On entry, the current maximum tracking rate is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The maximum tracking rate can range from
0.5 to 6 dBm/minute. Press [ENTER] to execute the change.
LOCAL CL Programs the local carrier loss for maximum, nominal, or hold.
On entry, the current status of the local carrier loss is displayed with the
flashing cursor on the first character. Use the arrow keys to select maximum,
nominal, or hold. Press [ENTER] to execute the change.
REMOTECL Programs the remote carrier loss for maximum, nominal, or hold.
On entry, the current status of the remote carrier loss is displayed with the
flashing cursor on the first character. Use the arrow keys to select maximum,
nominal, or hold. Press [ENTER] to execute the change.
