SDM-650B Satellite Modem Trojan Interface
Rev. 5 G–9
G.5 Front Panel Operation
The operation of the front panel has the same “look and feel” as the standard modem,
except there are a few additional commands for the Trojan interface.
Note: For general information on front panel operation, refer to Chapter 4.
Refer to Tables G-1 through G-8 for front panel menus and options for the SDM-650B
with the Trojan interface option installed.
G.5.1 Menus and Options Overview
Refer to Section G.5.2 for menu and option explanations.
The “T” after the software version designates “Trojan.”
Table G-1. Main Front Panel Menu (Trojan Interface)
Menus Submenus/Options Comments
SDM-650S
SW_4.13T This is an information-only screen.
SELECT CONFIG MOD
DEMOD
INTRFACE Go to Table G-2.
Go to Table G-3.
Go to Table G-4.
SELECT MONITOR Raw_BER
Corr_ BER
Eb/NO
SWP_FREQ
RXSignal Go to Table G-5.
Go to Table G-5.
Go to Table G-5.
Go to Table G-5.
Go to Table G-5.
SELECT FAULTS MOD Flts
DMD Flts
Ceq Flts Go to Table G-6.
Go to Table G-6.
Go to Table G-6.
SELECT StFAULTS MOD
DMD Flts
Ceq Flts
CLEAR?? Go to Table G-7.
Go to Table G-7.
Go to Table G-7.
Go to Table G-7.
SELECT UTILITY Time
Date
LAMP TEST??
ADD/PARITY/BAUD RATE
POW ADJ
OP MODE
FAST ACQ
FILTERS ADJUST
Assign TX_Fltrs
Assign RX_Fltrs Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
Go to Table G-8.
