Trojan Interface SDM-650B Satellite Modem
G–32 Rev. 5
G.6.4.5 Status Commands/Responses
G.6.4.5.1 Configuration
G.6.4.5.1.1 Modulator/Coder Configuration Status
The Modulator/Coder configuration status command causes a block of data to be returned
by the addressed modem. The block of data reflects the current configuration status of the
Modulator/Coder.
Command:
Response: >add/MCS_”cr”
RF_xxx”cr”
RF output (ON/OFF)
MF_nnn.nnnn”cr” Modulator frequency
MPO_snn.n”cr” Modulator Power Offset
MOP_snn.n”cr” Modulator Output Power
MR_nnn_mmmm.m”cr” Modulator rate
AMRA_nnn_mmmm.m”cr” Filter “A” assignment
AMRB_nnn_mmmm.m”cr” Filter “B” assignment
AMRC_nnn_mmmm.m”cr” Filter “C” assignment
AMRD_nnn_mmmm.m”cr” Filter “D” assignment
SE_xxx”cr” Scrambler enable (ON/OFF)
COM_xxx”cr” Carrier only mode (ON/OFF)
DENC_xxx”cr” Differential encoder (ON/OFF)
AMRV_nnn.mmmm.m”cr””lf”] Modulator variable rate assignment
(variable rate option only)
