Operation SDM-650B Satellite Modem
4–4 Rev. 5
The modem responds by beeping whenever a key is pressed.
• A single beep indicates that the key pressed was a valid entry, and the
appropriate action was taken.
• A double beep when a key is pressed indicates an invalid entry.
The modem front panel control uses a tree structured menu system (Tables 4-1 through
4-6) to access and execute all functions. The base level of this structure is the sign-on
message, which is displayed at the front panel upon modem power-up.
• Line 1 of the sign-on message is the modem model number.
• Line 2 is the version number of the firmware implemented in the modem.
The main level of the menu system is the Select menu, which may be accessed from the
base level by pressing any of the arrow keys. From the Select menu, any one of five
functional categories can be chosen:
• Configuration
• Monitor
• Faults
• Stored faults (StFaults)
• Utility
Use
[ ← ] and [ → ] to move from one selection to another. When the desired function is
displayed on line 2, enter that level by pressing [ENTER]. Once the desired the functional
level is entered, move to the desired function by using
[ ← ] and [ → ] .
4.1.3 Menus and Options Overview
Refer to Section 4.1.4 for menu and option explanations.
Table 4-1. Main Front Panel Menu (Standard)
Screen Submenus/Options Comments
SDM-650
SW_4.16 This is an information-only screen.
SELECT CONFIG
MONITOR
FAULTS
StFAULTS
UTILITY
Go to Table 4-2.
Go to Table 4-3.
Go to Table 4-4.
Go to Table 4-5.
Go to Table 4-6.
