Table F-9. Select Faults Menu (with AUPC)

Menus

Submenus/Options

Comments

Mod Flts
– – – – – – –

RF_Syn
Data_Clk
TClk_Syn
I-Channl
Q-Channl
AGC levl
Module

Dmd Flts
+ – + + + + – –

C_Detect
RF_Syn
Data Clk
I-Channl
Q-Channl
Dscrambl
BERthrsh
Module

CEq Flts
– – – – –

Battery
-12 volt
+12 volt
+5 volt
Intrface

TX_INTF
– –

TX_PLL
Clk_Act

RX_INTF
– – + – +

BUF_UNFL
BUF_OVFL
RX_PLL
Buff_Clk
MUX_lock
