SDM-650B Satellite Modem Operation
Rev. 5 4–5
Table 4-2. Select Configuration Menu
Menus Submenus/Options Comments
TX-x Code Rate x = A, B, C, D, or V
RX-x Code Rate x = A, B, C, D, or V
TX_Freq 50.0000 to 90.0000 MHz
or 100.000 to 180.000 MHz In 2.5 kHz steps.
RX_Freq 50.000 to 90.0000 MHz
or 100.000 to 180.000 MHz In 2.5 kHz steps.
RF_Out ON
OFF
TX_Power -5.0 dBm to -30 dBm In 0.5 dBm steps.
RFLoopBk ON
OFF
IFLoopBk ON
OFF
BBLoopBk ON
OFF
Scramblr ON
OFF
Dscrmblr ON
OFF
DifEncdr ON
OFF
TX_Clock Internal
External
RX_Clock Normal
Inverted
SWP_RACQ 0 to 999 Seconds
SWP_CNTR -25000 to +25000 Hz Displays information when fast
acquisition has been turned ON in the
Utility menu.
SWP_RNGE 0 to 50000 Hz Displays information when fast
acquisition has been turned ON in the
Utility menu.
SWP_DIR FORWARD +
REVERSE -
Displays information when fast
acquisition has been turned ON in the
Utility menu.
CW_Mode Center
Dual
Offset
BUF_clk Transmit
Receive
External
BUF_CNTR YES/NO?
BUF_SIZE 0 to 999
