10/07 Rev. AA MANUAL EASY PLUG Commands
All devices
A = TTX 600 --TLX 604 – Eagle B = TTX 300 Offline -- Cobra Offline D = TTX 300 Online –TTX 207 -- Cobra Online – Da Capo
E = TTX 450/650/674/675/950/1050 – Puma/Puma plus/Lion/Lion plus/Tiger/Tiger XXL -- S45/65/95/105 -- TDI/STDI/XXTREME
G = TTX 350 – Ocelot – TTK – Texxtile H = 64-xx –Chess x –TT4 – DPM – PEM – ALX 92x – AP 4.4/5.4
91
#YBz/dkcf/h/s/vo/a/TEXT#G TTX 207/Da Capo
#YBz/dkbcejgrwlm/h/s/vo/a/TEXT#G Group H
z = int Bar code number (see Tab. 8).
# Bar code # Bar code
0 EAN 8 14 MSI
1 EAN 13 15 EAN 128
2 UPCA 16 CODE 39 (3:1)
3 CODE 93 17 POSTCODE (guide and identity
code)
4 CODE 2/5 Interleaved 18 CODE 128 (UPS)
5 CODE 2/5 Matrix 19 CODE 39 (2,5:1)
6 CODE 2/5 5-line 20 CODE 2/5 Interleaved Ratio 1:3
7 CODE 39 21 CODE 2/5 Matrix Ratio 1:2,5
8 CODABAR 22 CODE 2/5 Matrix Ratio 1:3
9 UPCE 23 CODE 39 Extended
10 ADD ON 2 24 CODE 128 A
11 ADD ON 5 25 CODE 128 B
12 ITF 26 CODE 128 C
13 CODE 128 27 CODE 128 Pharmacy
Tab. 8 Bar code selection is done by inserting the appropriate number into the #YB
command.
Info-printout of a bar code list with print samples: See topic section „Info-
Printouts and Parameters“, parameter INFO > STA2 .
How to print a bar code list with print samples: Call up parameter PRINT
INFO > Font status (group H), or INFO > STA2 (groups E, G), respectively.
opt. d = 0 Bar code in normal write direction
= 1 Bar code rotated by 90 degrees
= 2 Bar code rotated by 180 degrees
= 3 Bar code rotated by 270 degrees
opt. k = M Bar code with plain-copy line
= O Bar code without plain-copy line
opt. b = A Position change of the plain-copy line. If the plain-copy line is normally
printed below the bar code, it is shifted by this option to the top of the bar
code, and the other way round.
opt. c = C A check digit according to Module 10 is calculated and printed.
Works only with 2/5 interleaved bar codes and with ITF bar code!
opt. e = V Bar code is verified.
Only with connected and activated OLV.
Only applicable for bar codes which are rotated by 0° or 180°.
