10/07 Rev. AA MANUAL EASY PLUG Commands
All devices
A = TTX 600 --TLX 604 – Eagle B = TTX 300 Offline -- Cobra Offline D = TTX 300 Online –TTX 207 -- Cobra Online – Da Capo
E = TTX 450/650/674/675/950/1050 – Puma/Puma plus/Lion/Lion plus/Tiger/Tiger XXL -- S45/65/95/105 -- TDI/STDI/XXTREME
G = TTX 350 – Ocelot – TTK – Texxtile H = 64-xx –Chess x –TT4 – DPM – PEM – ALX 92x – AP 4.4/5.4
20
Example #!X0 Status request with 0 ms delay period.
Example acknowledgement:
S0000A100M000000F065536K R2.02 H2.01
#!XP Parameter status
Definition
#!XP delivers a selection of parameter settings of the printer packed in one
answer string.
•
The answer string is 182 bytes long and contains all parameter settings
listed in the table below in the same order.
•
All parameter settings contained in the answer string are lined up without a
separating character.
•
Digits which are not used (see column no. of digits) are filled by preceding
blanks.
Syntax
#!XP Group H (only TT4)
Parameter No. of digits Example Allocation / Unit
Version number 16 „R1.10 HS 0.15„
Date 12 „Jun 15 2000“
Printer type 16 „TT4„
Infeed no. 1 „1“
Inf. change spd. 2 „8“ Inch/s
Print speed 2 „11“ Inch/s
Feed speed 2 „12“ Inch/s
Material type 1 „0“ 0 = endless
1 = punched
Material length 6 „175.4“ mm
Material width 6 „99.0“ mm
Punch offset 4 „-2“ „13“ mm
Bar code Multip. 2 „1“
Cut mode 1 „0“ 0 = Real 1:1
1 = Batch Mode
2 = Normal 1:1
Cut speed 2 „3“ Inch/s
Cut position 6 „2.0“ mm
Double cut 6 „10.0“ mm
UPC decoded line 1 „0“ 0 = In line
1 = Raised
X – print offset 6 „-1.0“ mm
Y – print offset 6 „0.0“ mm
Punch mode 1 „0“ 0 = Automatic
1 = Manuel
Punch level 3 „128“
