10/07 Rev. AA MANUAL EASY PLUG Commands
All devices
A = TTX 600 --TLX 604 – Eagle B = TTX 300 Offline -- Cobra Offline D = TTX 300 Online –TTX 207 -- Cobra Online – Da Capo
E = TTX 450/650/674/675/950/1050 – Puma/Puma plus/Lion/Lion plus/Tiger/Tiger XXL -- S45/65/95/105 -- TDI/STDI/XXTREME
G = TTX 350 – Ocelot – TTK – Texxtile H = 64-xx –Chess x –TT4 – DPM – PEM – ALX 92x – AP 4.4/5.4
76
S
#S Dispensing mode/position
Definition Defines the dispensing mode and dispensing position.
This command is only for printers in the dispenser version. The single start
function is not affected by it.
Syntax #Sm/p Groups D, E
m = B Batch mode:
– for materials with high separation values, i.e. not always suitable for
dispensing
– higher label capacity (output). The start of the label cannot be printed
over the length selected under SPOS or "p".
= E 1:1 mode: (not for Group D)
– for materials with low separation values which are suitable for
dispensing
– total surface of the label is printable. The capacity is somewhat reduced
because the label is pulled back to the zero line.
p = num Dispensing position (13 to 100 mm)
Distance from the back edge of the label to the zero line on the print head.
Example #SE/14 1:1 mode and dispensing position 14 mm
#SB Bar code definition
Definition of a bar code. Printing of the bar code requires a subsequent
#VW-command.
Command must be placed between #ER and #Q!
Syntax #SBz/kclbmrev/h/s#G Group H 1)
z = int Bar code number (see Tab. 8).
# Bar code # Bar code
0 EAN 8 14 MSI
1 EAN 13 15 EAN 128
2 UPCA 16 CODE 39 (3:1)
3 CODE 93 17 POSTCODE (guide and identity
code)
4 CODE 2/5 Interleaved 18 CODE 128 (UPS)
5 CODE 2/5 Matrix 19 CODE 39 (2,5:1)
6 CODE 2/5 5-line 20 CODE 2/5 Interleaved Ratio 1:3
7 CODE 39 21 CODE 2/5 Matrix Ratio 1:2,5
1)
AP 4.4: only with 16 MB RAM and firmware version 3.0 or higher.
