10/07 Rev. AA MANUAL EASY PLUG Commands
All devices
A = TTX 600 --TLX 604 – Eagle B = TTX 300 Offline -- Cobra Offline D = TTX 300 Online –TTX 207 -- Cobra Online – Da Capo
E = TTX 450/650/674/675/950/1050 – Puma/Puma plus/Lion/Lion plus/Tiger/Tiger XXL -- S45/65/95/105 -- TDI/STDI/XXTREME
G = TTX 350 – Ocelot – TTK – Texxtile H = 64-xx –Chess x –TT4 – DPM – PEM – ALX 92x – AP 4.4/5.4
80
h = int Row height
Row height = (h + 1) * PRINT PARAMETERS > Bar code Multip.
#SG Graphics definition
Definition of a graphic. Printing of the bar code requires a subsequent
#VW-command.
Command must be placed between #ER and #Q!
Syntax #SG#G Group H (without AP 4.4)
Example #SG#G
#T82#J75
#VW/L/"Graphic01.bmp" #G Graphics definition
Define print position
Print graphics
#SMX Maxicode definition
Definition of a “Maxicode” bar code. Printing of the bar code requires a
subsequent #VW-command.
Command must be placed between #ER and #Q!
Syntax #SMXz/x/y#G Group H (without AP 4.4)
z = int MaxiCode modes 2, 3, 4 and 6
x = int Symbol number for code-splitting (1 to 8)
y = int Number of symbols for code-splitting (1 to 8)
#SPF PDF 417 definition
Definition of a “PDF 417” bar code. Printing of the bar code requires a
subsequent #VW-command.
Command must be placed between #ER and #Q!
Syntax #SPFnt/s/l/z/w/h#G Group H (without AP 4.4)
n = Compression type
= 0 EXC mode (Extended alphanumeric Compaction Mode)
= 1 Binary ASCII Plus Mode
t = T Unidirectional reading
= (blank) Bi-directional reading
s = int Security Level (0 bis 8)
