MANUAL EASY PLUG
Commands
All
devices
A = TTX 600 --TLX 604 – Eagle B = TTX 300 Offline -- Cobra Offline D = TTX 300 Online –TTX 207 -- Cobra Online – Da Capo
E = TTX 450/650/674/675/950/1050 – Puma/Puma plus/Lion/Lion plus/Tiger/Tiger XXL -- S45/65/95/105 -- TDI/STDI/XXTREME
G = TTX 350 – Ocelot – TTK – Texxtile H = 64-xx –Chess x –TT4 – DPM – PEM – ALX 92x – AP 4.4/5.4
21
Parameter
No. of digits
Example
Allocation / Unit
Interface
1
„0“
0 = RS232
1 = Centronics
2 = RS422
3 = RS485
Baud rate
1
„2“
0 = 300
1 = 600
2 = 1200
3 = 2400
4 = 4800
5 = 9600
6 = 19200
7 = 38400
8 = 115200
No. of data bits
1
„8“
Parity
1
„0“
0 = Odd
1 = Even
2 = Non
3 = Always zero
Stop bits
1
„2“
Data synch.
1
„0“
0 = RTS/CTS
1 = XON/XOFF
Spooler mode
1
„0“
0 = Mult. print jobs
1 = Single print job
Printer ID no.
2
„1“
Spooler size
3
„64“
KByte
w/wo magazine
1
„1“
0 = with
1 = without
Print emulation
1
„0“
0 = Easyplug
1 = Lineprinter
2 = Hexdump
Character sets
1
„9“
0 = USA
1 = England
2 = France
3 = Germany
4 = Italy
5 = Swedem
6 = Spain
7 = Norway
8 = Special function
9 = IBM
Character filter
1
„0“
0 = Character > 20 H.
1 = All characters
Light sens. type
1
„0“
0 = Punched
1 = Reflex
2 = Full Size
Sens. punch LS
3
„100“
%
