Q U I C K R E F E R E N C E
This Quick Reference contains supply loading information and
general care and maintenance procedures for the Monarch® Sierra
Sport4™ 9493™ printer. For more detailed information, refer to the
Operator’s Handbook available on our Web site
(www.monarch.com).
U s i n g t h e B a t t e r y
You must charge the battery before using it for the first time.
Refer to the Operator’s Handbook for important battery information.
1. Review the safety information in the Regulatory Compliance
document included with your printer.
2. Turn off the printer when you change batteries.
3. Lay the printer down so the back of the printer faces up.
4. Remove the plastic from a new battery.
5. Slide the battery into the battery well in the bottom of the
printer until it latches into place.
L a t c h
