1–6 Chapter 1: About This MegaCore Function
Resource Utilization
Serial Digital Interface (SDI) MegaCore Function February 2013 Altera Corporation
User Guide
Resource Utilization
Table 1–7 lists the typical resource utilization for various parameters with the
Quartus II software, version 11.1.
1 The resource utilization of the MegaCore function is based on the bidirectional
interface settings unless otherwise specified.
Table 1–7. Resource Utilization (Part 1 of 2)
Device Video Standard LEs Combinational ALUTs Logic Registers
Arria GX
SD-SDI — 834 640
HD-SDI — 919 683
3G-SDI — 1,161 865
Dual link HD-SDI — 1,906 1,423
Dual standard receiver — 1,188 831
Dual standard transmitter — 247 185
Triple standard — 1,794 1,215
Arria II GX
SD-SDI — 839 680
HD-SDI — 978 833
3G HD-SDI — 1,259 1,015
Dual-Link HD-SDI — 2,029 1,711
Dual standard receiver — 1,257 926
Dual standard transmitter — 267 180
Triple standard — 1,891 1,305
Arria V
SD-SDI — 1,189 920
HD-SDI — 1,185 910
3G-SDI — 1,444 1,142
Dual link HD-SDI — 2,446 1,880
Dual standard receiver — 1,605 1,175
Dual standard transmitter — 349 269
Triple standard — 2,273 1,677
Cyclone SD-SDI 875 — —
Cyclone II SD-SDI 867 — —
Cyclone III SD-SDI 874 — —
Cyclone III LS SD-SDI 929 — —
Cyclone IV GX
(EP4CGX15,
EP4CGX30)
SD-SDI 916 — —
