i.LON SmartServer 2.0 Programming Tools User’s Guide 239
à Use i.LON SmartServer 2.0 Programming Tool to
upload FPM executable module (.app or .drv
extension) to root/modules/user/<YourCompany>
folder on SmartServer flash disk. Must have FPM license on SmartServer to
upload FPMs.
Select Default Web Page check box in
Deployment Settings window of Install
FPM Module dialog to create custom
FPM configuration Web page for FPM
applications.
à If you are deploying an FPM driver, reboot the
SmartServer.
à Use SmartServer to verify that a network
management service has been selected (LNS or
Standalone). If using LNS mode (LNS Auto or LNS
Manual), FPM devices must have static
interfaces.
Must use an LNS mode in order to bind
data points in your FPM application to
other data points with L
ON W ORKS
connections.
Must use Standalone mode if FPM devices
use dynamic interfaces.
à Use SmartServer to add new internal FPM device on
L
ON W ORKS channel.
If FPM device has static interface, select
XIF file from root/lonWorks/Import/
<YourCompany> folder.
If FPM device has dynamic interface,
select v40 XIF file from
root/lonworks/import/Echelon/iLON100
folder.
à If FPM device has dynamic interface, add functional
block to device based on UFPT used by FPM.
à If binding FPM data points with L ON W ORKS
connections, commission FPM device using
SmartServer or LonMaker tool
Can commission device from SmartServer
tree or LNS tree in SmartServer Web
interface.
Once FPM device is commissioned in the
LonMaker tool, cannot use the
SmartServer to decommission the device
or set the device application offline.
Can only use the LonMaker tool to
decommission and re-commission the
device and set the device application
online or offline.
à Test FPM application with View – Data Points Web
page in SmartServer Web interface.
à Connect FPM data points with L ON W ORKS
connections or Web connections.
Can create LonWorks connections with
LNS tree in SmartServer Web interface or
the LonMaker tool.
Can create Web connections with
SmartServer tree in SmartServer Web
interface
