CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 90 of 350
DUT(config)#interface eth-0-9 Specify the interface (eth-0-9)to be
configured and enter the Interface
mode
DUT(config-if)# switchport mode trunk Set the switching characteristics of
this interface to trunk mode.
DUT(config-if)# switchport trunk allowed vlan all Enable all VLAN IDs on this port.
DUT (config-if)#ethernet cfm mep level 5 down mpid 99 vlan 30 Configure a maintenance end point
(MEP).
DUT (config-if)# no shutdown Bring up the interface.
DUT (config-if)#exit Exit the Interface mode
DUT (config)#ethernet cfm enable Enable CFM globally.
DUT (config)#ethernet cfm cc level 5 vlan 30 interval 10000 Configure the interval in the selected
service instance (MA) instance with
the configured domain-level.
DUT (config)#ethernet cfm cc enable level 5 vlan 30 Enable continuity check in the
selected service instance (MA)
instance with the configured
domain-level.
DUT(config-if)# end Exit the Interface mode.
Validation Commands
The following command on machine 1 gives the connectivity details of the local machine DUT1
for the configured domain.
DUT1#show ethernet cfm maintenance-points remote
MPID Level Vlan Remote Mac Age(min) Service ID
------------------------------------------------------------
99 5 30 d427.e2f1.dc09 0 MA10
DUT1#show ethernet cfm maintenance-points local mep
MPID Level Type Vlan Port CC Status Mac Address Domain Name
-------------------------------------------------------------------------------------------------
66 5 MEP-D 30 eth-0-9 Enabled c23d.d0ed.0309
customer
2) Linktrace checks
DUT1# linktrace ethernet mep 99 level 5 vlan 30 ttl 64 timeout 5
Sending Ethernet CFM linktrace messages,TTL is 64.Per-Hop Timeout is 10 seconds:
-------------------------------
Received Hops: 1
-------------------------------
