CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 234 of 350
4010 vlan id which used for vpls
function.
DUT1(config)#mpls vpls v4 100 Create a VPLS instance and
come into the VPLS instance
mode.
DUT1(config-vpls)#vpls-peer 11.11.1.1
raw Add a PE for VPLS instance.
DUT1(config-vpls)#vpls-peer 11.11.3.3
raw Add a PE for VPLS instance.
DUT1(config-vpls)#exit Exit VPLS instance mode.
DUT1(config)#interface eth-0-1 Enter the Interface mode
• eth-0-1—Specify the
interface
DUT1(config-if)#mpls-vpls v4 Bind an interface to a VPLS
instance.
DUT1(config-if)#exit Exit the Interface mode.
DUT1(config)#interface eth-0-2 Enter the Interface mode
• eth-0-1—Specify the
interface
DUT1(config-if)#switchport mode
trunk Configure trunk mode on the
port.
DUT1(config-if)#mpls-vpls v4 vlan 2 Bind an interface to a VPLS
instance.
DUT1(config-if)# mpls-vpls v4 vlan 3 Bind an interface to a VPLS
instance.
DUT1(config-if)# mpls-vpls v4 vlan 4 Bind an interface to a VPLS
instance.
DUT1(config-if)# mpls-vpls v4 vlan 5 Bind an interface to a VPLS
instance.
DUT1(config-if)#exit Exit the Interface mode.
Configuring the VPLS on PE3
Command Description
DUT1#configure terminal Enter the Configure mode.
