CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 315 of 350
Enabling IEEE 802.1x authentication
In this example, the Radius Server keeps the Client information, validating the identity of the
Client and updating the switch about the authentication status of the client. The Switch is the
physical access between the two Clients and the Server. It requests information from the client,
relays information to the Server and then back to the Client.
To configure 802.1x authentication, first enable authentication on ports eth-0-1 and then specify
the Radius Server IP address and port.
DUT# configure terminal Enter the Configure mode.
DUT(config)# dot1x system-auth-ctrl Enable IEEE 802.1x authentication globally on the switch.
DUT(config)#radius-server host
202.38.100.7 key test Specify the radius server and the shared key
DUT(config)#interface eth-0-1 Enter the interface mode
DUT(config-if)#swichport mode access Set the port to access mode
DUT(config-if)# dot1x port-control auto Enable IEEE 802.1x authentication on the interface
DUT(config-if)# dot1x port-control dir
both Set the control direction as both
DUT(config-if)# dot1x reauthentication Enable reauthentication
DUT(config-if)# dot1x timeout
re-authperiod 7200 Set the timer: re-auth period to 2 hours(7200)
DUT(config)# exit Exit interface mode and enter the Configure mode.
DUT(config)#interface eth-0-3 Enter the interface mode
